Every road starts from the ground up. If the ground is weak, the road won’t last. That’s why geotechnical considerations matter in pavement subgrade design.

Poor soil means cracks, bumps, and early failure. Excess moisture or soft subgrades can cut pavement life in half. Roads built on clay or organic soil often fail within years.

Soil testing for roads helps avoid costly mistakes. This article covers pavement soil analysis and geotechnical investigations. These can help design strong, long-lasting roads

Geotechnical factors relate to soil and how it behaves under load. Pavement sits on soil. If that soil shifts or weakens, so does the road.

Key geotechnical elements include:

• Subgrade: This is the earth structure on which the building of the pavement is fitted.
• Soil strength: It is the bearing capacity. This will determine the load that the soil can carry without being deformed.
• Moisture content: An excess of water in the soil makes the soil less bearing in weight.
• Stability: This should assist in the forecasting of heaving and setting. It should also tell the overall performance.

Testing is key. It shows what kind of soil is present and what treatments it needs. In California, agencies like Caltrans and LADBS require detailed geotechnical reports. They require it for any road design or reconstruction.

Soil’s strength, composition, and seasonal behavior must be known. It is essential to prevent premature failure. These insights also help engineers choose the right pavement thickness. These also help in selecting materials and the stabilization method.

Site investigation is used to obtain a picture of what makes up the ground. Boreholes, test pits, and geophysical devices are some of the tools. Engineers use to determine the subsurface.

Soil samples are tested in labs for:

• Grain size
• Plasticity
• Shear strength
• Compressibility

Common in-field tests:

• SPT (Standard Penetration Test): Measures resistance of soil to penetration.
• CPT (Cone Penetration Test): Gives a continuous profile of soil strength.

These tests follow ASTM and AASHTO guidelines. In California, Caltrans test methods (CTM) are widely adopted. They ensure accurate, consistent results.

Borehole data helps reveal buried hazards. These may be collapsible soil, groundwater tables, or organic matter. It also flags issues like landslides or fault lines in hilly zones.

Local permitting authorities require the submission of different documents. Los Angeles County and LADBS,  requires boring logs, lab results, and a certified geotechnical report.

The right inspections prevent project delays and the risky projects or the budgets. Properly framed inspections safeguard schedules, jobs and project budgets. I

The subgrade is the most critical part of any pavement system. It bears the entire weight of traffic, climate effects, and construction materials above.

Its performance is measured using:

• CBR (California Bearing Ratio): Tells how well soil resists penetration.
• R-Value: Reflects performance under wet conditions.
• Resilient Modulus (Mr): Used in advanced modelling.

CBR is tested by compacting soil and pushing a plunger into it. Values below 5% suggest very weak soils. Those above 20% are good candidates for direct support.

In Los Angeles and nearby counties, many natural soils fail to meet the minimum CBR threshold. Especially clays and silts. Engineers often replace or treat them with additives.

Good subgrade design boosts pavement life and cuts repair costs. It also helps achieve uniform load distribution and minimizes rutting.

Not all soils act the same. Engineers classify soils using:

• USCS (Unified Soil Classification System): Based on grain size and plasticity.
• AASHTO Classification: Focused on road performance.

Gravel and sand are ideal. They compact well and drain fast. Silt is good at holding water; thus, it is squishy. Clay is affected by humidity; it swells and shrinks.

Soil class affects:

• Load support
• Moisture retention
• Frost susceptibility

In Southern California, expansive clays are common in hillside areas. If untreated, they cause severe pavement damage. Lime or cement stabilization is often used.

The California Geological Survey (CGS) provides detailed maps. These maps show regional soil types and problem areas. These are essential for preliminary planning.

Water weakens soil and damages pavement. Moisture changes lead to heaving, settlement, and cracking.

Drainage systems are designed to:

• Prevent water from reaching the subgrade
• Remove infiltrated water quickly
• Maintain stable moisture content

Techniques include:

• Capillary barriers: Stop water from rising into pavement layers.
• Subdrains: Pipe systems that remove groundwater.
• Surface grading: Hills and mounds that cause water to move away from.

Storm intensity, soil absorbance and road height should also be taken into account in the drainage design. In places like Long Beach, high water tables demand advanced drainage systems.

LA County DPW requires hydrology reports and drainage plans. These are must for all new road designs.

Weak soils must be improved to support traffic loads and reduce long-term deformation.

1. Mechanical Stabilization

• Compaction densifies soil, reducing voids and increasing strength.
• Blending mixes poor soils with better ones or granular material.

2. Chemical Stabilization

• Lime: Reacts with clay minerals to improve strength.
• Cement: Ideal for silty or sandy soils needing rapid gains.
• Fly Ash: Enhances lime reactivity in clayey soils.

3. Geosynthetics

• Geotextiles: Separate weak soil from aggregates.
• Geogrids: Reinforce and spread load.

Stabilisation improves shear strength, reduces plasticity, and increases bearing capacity. In California, sustainable stabilization is encouraged. CalRecycle encourages the use of fly ash and reclaimed materials for stabilization.

Stabilisation helps to minimize the amount of required pavement material. Thus, it saves on transportation and material expenses.

Mainly, seasonal changes make the soil movement unfavourable to pavement.

Frost heave: Frozen water is expanded; hence the earth and road rise up as a result.

Shrink-swell: the swell effect of a clay, in which the clay expands when it is wet and contracts when dry.

Frost is not plentiful in South California but the mountainous areas even experience freezing during certain times of the year. San Bernardino, for example, faces shrink-swell risks due to expansive clay layers.

To control seasonal effects:

• Replace expansive soils
• Treat with lime
• Use moisture control barriers

The California Building Code requires expansive soil testing and mitigation for public roads.

Geotechnical data feeds into pavement structure models. Tools like AASHTOWare and MEPDG use this data to simulate:

• Traffic loading over time
• Material fatigue
• Climate effects

Inputs include:

• CBR or Resilient Modulus
• Seasonal moisture and temperature
• Material layers and thickness

The performance predictions are more accurate due to accurate geotechnical input. The engineers liaise to match structural and geotechnical designs for cost-effectiveness and reliability.

Designers also adjust base/subbase layer thickness. Usually, it is based on local soil conditions and expected traffic.

In Lancaster, CA, a rural road resurfacing project skipped a proper geotechnical evaluation. Just 18 months later, the pavement showed severe cracking and surface settlement.

What Went Wrong

• The subgrade was highly expansive clay with low CBR values.
• No soil testing or stabilization was done during repaving.
• Water infiltration and seasonal moisture cycles triggered swelling and shrinkage.

The result? Longitudinal and transverse cracks formed along the road. Some sections heaved upward, others settled into depressions.

Financial Impact

• Complete reconstruction was required within two years.
• Project costs doubled due to rework and emergency stabilization.

A simple CBR test and borehole log would have revealed the soil risks. It led to proactive stabilization and likely avoided the failure altogether.

Geotechnical work is the backbone of lasting pavement. Without proper soil analysis, even the best pavement materials can fail. The effects of subgrade problems are cracks, water damage and expensive repairs.

Due to early assessment of soil, smart decisions are made. It is important due to the contribution of proper drainage, soil stabilisation, and correct testing.

The soil textures are extremely diverse in the Southern Californian region. It ranges from soft beach sand to vast clay in rural areas. That’s why every project must begin with a detailed geotechnical investigation. These tests guide design teams in selecting the right pavement structure.

They help avoid overdesign and save budget. More importantly, they protect roads from early failure.

Geotechnical engineers and road designers need to collaborate. When the proper data is used, pavements will last up to 20-30 years with little to no maintenance. That is what ground-up construction can do. That’s the power of building from the ground up—literally.

Call to Action: Planning a road, parking lot, or pavement project? Don’t skip the soil work. First, carry out a geotechnical exploration survey by a registered Geotechnical exploration company.

In Southern California, contact the California Geological Survey, LADBS, or LA County DPW. One little investment in testing can save millions in repair of the long run. Build smarter. Build stronger. Begin with the soil.
